| Place of Origin |
Jiangsu China (Mainland) |
| Brand Name |
Allwin |
| Model Number |
CS5601 |
| Power |
Electronic |
| Usage |
Auto Testing Machine |
With the function of zero passage start-up and zero passage cut off With voltage testers all the features Test voltage of insulation resistance has three gears: 250V/500V/1000V Ceiling insulation resistance up to 10000MΩ (10GΩ), more adaptive W → I, I → W automatic conversion Insulation Test automatic transmission ModelCS5600CS5601CS5602CS5603hipot Output voltage(kV) (0-5)(AC)(0-5)(AC/DC)(0-5)(AC)(0-5)(AC/DC)Output current(mA) 0~100)(AC)0~100/20)(AC/DC)0~20)(AC)(0~20/10)(AC/DC)Test time(S) (0.1~999)(0.1~999)(0.1~999)(0.1~999)Transformer capacity 500VA500VA100VA100VACapacity ±(2%+2 counts)±(2%+2 counts )±(2%+2 counts )±(2%+2 counts )IRIR Range (1~10000)MΩ(1~10000)MΩ(1~10000)MΩ(1~10000)MΩVoltage range(kV) (250/500/1000)(250/500/1000)(250/500/1000)(250/500/1000)Accuracy ±(5%+5 counts )±(5%+5 counts )±(5%+5 counts )±(5%+5 counts )Dimensions(width×height×deep)320mm×150mm×350mm320mm×150mm×290mmWeight(about)17.4kg(net weight)17kg( net weight )12.3kg( net weight )11.5kg( net weight )19.6kg(shipping weight)18.9kg( shipping weight )14.1kg( shipping weight )13.3kg( shipping weight )
